• 18KW H1800 outdoor power cabinet
• Outdoor Power Cabinet

  K&M All in One power cabinet provides space for, up to two Nokia AirScale BBU sub racks (6U), user equipment (6U/15kW, 5U/24kW) and either VRLA or Li-ion batteries (16U).

  Structure Size
• 48V 9U 24kW Compact System

  HHY48400-H9A3 is an embedded power supply system that supplies power to communication equipment of -48Vdc

  series and the maximum output current is 400A.

• 48V 5U 18kW Compact System

  48VDC (200A/400A) Power supply system description

• Embedded DC Power System
• Lithium Iron Phosphate(LiFePO4)Battery
• Outdoor Energy Storage Cabinet

  Introduction

  The whole system is plug-and-play, easy to transport, install and maintain.lt consists of battery module,PCS, STS (optional), MPPT (optional), control system, fire control system, and temperature control system, monitoring system one-stop integration, through the synergy of the system components to achieve.

  lt adopts AC coupled micro grid structure, PCS, load, grid, and access to AC bus, and the corresponding control strategy is developed according to the actual case to ensure the safety of power supply.

  The battery cluster consists of 21 modules connected in series, and the whole battery system is controlled by BCM to monitor the cluster voltage and current in real time.

  The battery module consists of 10200 AhLiFePO4cells; distributed BMM control system with functions of collecting battery voltage, collecting battery temperature, and battery equalization to ensure the module works

  Effectively and safely







  PRODUCT FEATURES

  ⚫Adopt automotive grade high performance lithium iron phosphate (LFP) battery, safe and reliable.

  ⚫Intelligent temperature control to ensure optimal temperature environment and lower system power consumption.

  ⚫Real-time data backup.

  ⚫Automatic fire fighting system with good safety.

  ⚫Support parallel and off-grid switching function.

  ⚫One button start, automatic operation, support multiple parallel connection.

  ⚫Protection class IP55, suitable for outdoor use.

  ⚫Four layers of safety protection design, safe and reliable.

  ⚫Support remote viewing service.

  ◎Model	30Kw/100kWh	60Kw/147.8kWh
  ◎Battery parameters
  Cell Type	LFP-220Ah	LFP-220Ah
  Module Model	IP10S	IP10S
  Battery Cluster Configuration	1P150S（15Module）	IP210(21Module)
  System Configuration	1*1P150S	1*IP210S
  Battery Capacity（BOL）	100kWh	147.84kWh
  Battery voltage range	420V-540V	588V-756V
  ◎AC on-grid parameters
  Grid Type	3P4W	3P4W
  Rated charge/discharge power	30KW	60kW
  Rated grid voltage	AC400V	AC400V
  Rated grid frequency	50Hz	60Hz
  Frequency range	±5Hz	±5Hz
  Rated current	43A	86A
  Power Factor	1（Ahead）~1（Lag）	1（Ahead）~1（Lag）
  Output Harmonics	≤3%	≤3%
  ◎AC off-grid parameters
  Rated output power	30KW	60KW
  Rated output voltage	AC400V	AC400V
  Rated output frequency	50Hz	50Hz
  Rated current	43A	86A
  Voltage accuracy	1%	1%
  Frequency accuracy	0.2Hz	0.2Hz
  ◎General parameters
  Dimension (W*D*H)	1861*1835*1267mm	1861*1835*1267mm
  Weight	1950kg	2200kg
  IP Protection Rating	IP55（Battery room）IP53(Electrical room)	IP55（Battery room）IP53(Electrical room)
  Seismic Intensity Rating	8（IEC60980）	8（IEC60980）
  Anti-corrosion grade	C3	C3
  Operating temperature【1】	-20℃～50℃	-20℃～50℃
  Relative Humidity	0-95%（Non-condensing）	0-95%（Non-condensing）
  Working altitude【2】	＜2000m	＜2000m
  Cooling method	Battery section: air conditioning Power section: forced air cooling	Battery section: air conditioning Power section: forced air cooling
  Noise	≤75dB	≤75dB
  System efficiency	≥88%	≥88%
  Cycle life	5 years or more than 2000 times	5 years or more than 2000 times
  Fire Fighting System	Automatic fire extinguishing	Automatic fire extinguishing
  Fire extinguishing media	FM200	FM200
  Communication Interface	Ethernet	Ethernet
  Communication protocols	Modbus TCP/IP	Modbus TCP/IP
  Warranty	3 years	3 years
  ◎Photovoltaic side parameters (optional)
  Maximum input module power	30KW	60KW
  MPPT Voltage Range	200V-420V	200V-580V
  Number of MPPT paths	1	1
  Number of PV input channels	1	1
  Maximum input current	100A	100A

  ◎ Notes：

  【1】The system will be derated when the ambient temperature exceeds 45℃.

  【2】The system will be derated when the altitude is between 2000 and 3000m.

  ◎Standard Certification：

  【1】System: GB_T 36558, IEC 62933

  【2】PCS: GB_T 34120

  TYPICAL SYSTEM LAYOUTS




  ◎ Notes： STS are available as options.




  On and off-grid (seamless switching)
• Lithium lron Phosphate (LiFePo4)Battery

  Longer Cycle Life: Offers up to 20 times longer cycle life and fivetimes longerfloat/calendar life than lead acid battery, helping tominimize replacement cost and reduce total cost of ownership.




  Lighter Weight: About 40% of the weight of a comparable leadacid battery.A'drop in'replacement for lead acid batteries.




  Higher Power: Delivers twice power oflead acid battery, evenhigh discharge rate, while maintaining high energy capacity.




  Wider Temperature Range:-20C~60'C




  Superior Safety: Lithium lron Phosphate chemistry eliminatesthe risk of explosion or combustion due to high impact, overchargingor short circuit situation.
